Nozzle Type

Arrow CM 16A Spray Gun

Spray Gun Specifications

Voltage/Frequency/ Watts/Current:  110V / 220V AC 50 / 60 Hz 40W/500mA Solvent Spill Proof System : Yes
Insulation: Class 1 Jar Capacity: 700ml
Extended Nozzle : Yes (Bent at 30 deg) Output per Second (Ml): 1.65ml
Spray Type: Adjustable from Mist spray to Straight Line High Velocity Spray Output Pressure: 1900 psi
Pressure Adjustment: Yes Rated Usage / Rest Time: 15 Sec On / 30 Sec Off
Earthed: Yes Pilferproof Shrink Packed: Yes
Electric Plug / Wire Length: 3 pin / 3 metres Package includes : 1 Unit Spray Gun, Spares Set
Fuse Protection: Yes - Replaceable Glass Fuse 5x20mm ; 800mA Identification Unique Serial Number: Yes
Body: Mirror Finished Impact Resistant Aluminium Security Genuine Product Hologram: Yes
Inductor Coil : Flame Retardant Glass Filled Nylon and High Temperature Resistant Copper Wire, Special Electrical Steel Unit Weight - Dry / With Solvent : 1.2 kgs / 1.7 kgs
Switch (Press to On / Release to Off): Flame Retardant Plastic with Copper Contacts Unit Weight - One Pc Packed: 1.50 kgs
Internal Wiring: Heat Resistant Teflon Coated Wire of 600V Rating Pcs / Carton: 10
Cylinder Assembly: Special Bronze alloy with Superfinished Piston Bore Carton Weight: 16.6 kgs
Piston: Hardchromed & Superfinished SS Carton Size : 75x27x52cms
Solvent: As suitable to the application other than Flammable Solvents Country of Origin: India
( Arrow CM16A model of spray gun is made from high heat resistant plastic raw-materials and is fitted with adjustable nozzle, which helps the spray to be varied from straight-line-spray to a mist type of spray. It is very ideal for users who need to clean different thickness of fabrics. The internal wirings can sustain high temperatures, the 3 meter wire does not restrict your movements, individually shrink packed boxes ensure your product is not tampered with, and our genuine "Arrow" brand hologram provides for best of quality product to you. The spray gun is also 'CE' certified. )
